Draw.Region()

View as Markdown

Definition

Draws a region on a chart.

Method Return Value

A Region object that represents the draw object.

Syntax

Draw.Region(NinjaScriptBase owner, string tag, int startBarsAgo, int endBarsAgo, ISeries\<double\> series, double price, Brush areaBrush, int areaOpacity, int displacement = 0)

Draw.Region(NinjaScriptBase owner, string tag, int startBarsAgo, int endBarsAgo, ISeries\<double\> series1, ISeries\<double\> series2, Brush outlineBrush, Brush areaBrush, int areaOpacity, [int displacement])

Draw.Region(NinjaScriptBase owner, string tag, DateTime startTime, DateTime endTime, ISeries\<double\> series, double price, Brush areaBrush, int areaOpacity)

Draw.Region(NinjaScriptBase owner, string tag, DateTime startTime, DateTime endTime, ISeries\<double\> series1, ISeries\<double\> series2, Brush outlineBrush, Brush areaBrush, int areaOpacity)

Parameters

ParameterDescription
ownerThe hosting NinjaScript object which is calling the draw method. Typically will be the object which is calling the draw method (e.g., “this”).
tagA user defined unique id used to reference the draw object. For example, if you pass in a value of “myTag”, each time this tag is used, the same draw object is modified. If unique tags are used each time, a new draw object will be created each time.
startBarsAgoThe starting bar (x axis co-ordinate) where the draw object will be drawn. For example, a value of 10 would paint the draw object 10 bars back.
startTimeThe starting time where the draw object will be drawn.
endBarsAgoThe end bar (x axis co-ordinate) where the draw object will terminate.
endTimeThe end time where the draw object will terminate.
series, series1, series2Any Series<double> type object such as an indicator, Close, High, Low etc. The value of the object will represent a y value.
priceAny double value.
outlineBrushThe brush used to color the region outline of draw object (reference).
areaBrushThe brush used to color the fill region area of the draw object (reference).
areaOpacitySets the level of transparency for the fill color. Valid values between 0 - 100. (0 = completely transparent, 100 = no opacity).
displacementAn optional parameter which will offset the barsAgo value for the Series<double> value used to match the desired Displacement. Default value is 0.

Examples

1// Draw a region between upper and lower Bollinger bands
2Draw.Region(this, "tag1", CurrentBar, 0, Bollinger(2, 14).Upper, Bollinger(2, 14).Lower, null, Brushes.Blue, 50);

Tips

  1. Pass in null to the “outlineColor” parameter if you do not want to have an outline color.
  2. If you wanted to fill a region between a value (20 period simple moving average) and the upper edge of the chart, pass in an extreme value to the “y” parameter such as 1000000.
  3. Should you be drawing regions based on Series<double> objects instead of indicator plots, be sure to create the Series<double> with the MaximumBarsLookBack.Infinite parameter if the region you are drawing would be maintained on the chart for more than 256 bars back.
