TextFixed

Definition

Represents an interface that exposes information regarding a Text Fixed IDrawingTool.

Methods and Properties

Anchor	YPixelOffset	Alignment	AreaOpacity	AreaBrush	DisplayText	TextBrush	Font	OutlineStroke	TextPosition
An IDrawingTool’s ChartAnchor representing the point of the drawing object	An int value representing the offset value in pixels from within the text box area	Possible values are: TextAlignment.Center TextAlignment.Far TextAlignment.Near TextAlignment.Justify (reference)	An int value representing the opacity of the area color	A Brush class representing the fill color of the text box	A string value representing the text to be drawn	A Brush class representing the color of the text	A Font object representing the font for the text	The Stroke object used to outline the text box	Possible values are: TextPosition.BottomLeft TextPosition.BottomRight TextPosition.Center TextPosition.TopLeft TextPosition.TopRight

Examples

// Instantiate a TextFixed object
TextFixed myTF = Draw.TextFixed(this, "tag1", "Text to draw", TextPosition.TopRight);

// Change the object's TextPosition
myTF.TextPosition = TextPosition.Center;
