You can use NinjaScript to draw custom shapes, lines, text and colors on price and indicator panels from both Indicators and Strategies.

Draw Methods and Associated Return Types

Draw Method	Return Type
Draw.AndrewsPitchfork()	AndrewsPitchfork
Draw.Arc()	Arc
Draw.ArrowDown()	ArrowDown
Draw.ArrowLine()	ArrowLine
Draw.ArrowUp()	ArrowUp
Draw.Diamond()	Diamond
Draw.Dot()	Dot
Draw.Ellipse()	Ellipse
Draw.ExtendedLine()	ExtendedLine
Draw.FibonacciCircle()	FibonacciCircle
Draw.FibonacciExtensions()	FibonacciExtensions
Draw.FibonacciRetracements()	FibonacciRetracements
Draw.FibonacciTimeExtensions()	FibonacciTimeExtensions
Draw.GannFan()	GannFan
Draw.HorizontalLine()	HorizontalLine
Draw.Line()	Line
Draw.Pathtool()	Pathtool
Draw.Polygon()	Polygon
Draw.Ray()	Ray
Draw.Rectangle()	Rectangle
Draw.Region()	Region
Draw.RegionHighlightX()	RegionHighlightX
Draw.RegionHighlightY()	RegionHighlightY
Draw.RegressionChannel()	RegressionChannel
Draw.RiskReward()	RiskReward
Draw.Ruler()	Ruler
Draw.Square()	Square
Draw.Text()	Text
Draw.TextFixed()	TextFixed
Draw.TimeCycles()	TimeCycles
Draw.TrendChannel()	TrendChannel
Draw.Triangle()	Triangle
Draw.TriangleDown()	TriangleDown
Draw.TriangleUp()	TriangleUp
Draw.VerticalLine()	VerticalLine

Property	Description
AllowRemovalOfDrawObjects	Determines if programmatically drawn DrawObjects can be manually removed from the chart
BackBrush	Sets the brush used for painting the chart panel’s background color for the current bar
BackBrushAll	Sets the brush used for painting the chart’s background color for the current bar
BackBrushes	A collection of historical brushes used for the background colors for the chart panel
BackBrushesAll	A collection of historical brushes used for the background colors for all chart panels
BarBrush	Sets the brush used for painting the color of a price bar’s body
BarBrushes	A collection of historical brushes used for painting the color of a price bar’s body
Brushes	A collection of static, predefined Brushes supplied by the .NET Framework
CandleOutlineBrush	Sets the outline Brush of a candlestick
CandleOutlineBrushes	A collection of historical outline brushes for candlesticks
DrawObjects	A collection holding all of the drawn chart objects for the primary bar series
IDrawingTool	Represents an interface that exposes information regarding a drawn chart object
RemoveDrawObject()	Removes a draw object from the chart based on its tag value
RemoveDrawObjects()	Removes all draw objects originating from the indicator or strategy from the chart
SimpleFont Class	Defines a particular font configuration

Custom graphics for custom indicators can be painted on either the price panel or indicator panel. You could for example have a custom indicator displayed in an indicator panel yet have associated custom graphics painted on the price panel. The “DrawOnPricePanel” property is set to true by default, which means that custom graphics will always be painted on the price panel, even if the indicator is plotted in a separate panel. If you want your custom graphics to be plotted on the indicator panel, set this property to false in the OnStateChange() method of your custom indicator.
Set unique tag values for each draw object, unless you intend for new draw objects to replace existing objects with the same tag. A common trick is to incorporate the bar number as part of the unique tag identifier. For example, if you wanted to draw a dot that indicated a buying condition above a bar, you could express it: Draw.Dot(this, CurrentBar.ToString() + “Buy”, false, 0, High[0] + TickSize, Brushes.ForestGreen);
Draw methods will not work if they are called from the OnStateChange() method.
